Shielding sheets applied to WPC + MST + NFC 3Combo antenna of smartphones
- High B, High μ & Low loss
- Higher Charging efficiency
Can be used as Tx and Rx shielding sheet
| Grade | NS-B12X | NS-B12Y |
|---|---|---|
| Materials | Nanocrystalline | Nanocrystalline |
| Widht Size(mm) | 58mm , 63mm, 66mm | 58mm , 63mm, 67mm |
| Length Size(mm) | free size | free size |
| Thickness(mm) | 0.03~0.14 | 0.03~0.14 |
| Number of layers | 1~5Layer | 1~5Layer |
| μ' @100kHz | 1400 | 700 |
| μ' @100kHz | 137 | 50 |
| Bm(mT) | 1230 | 1230 |
| Pcv(mW/cc) @25℃, 250mT, 100kHz | 1050 | 650 |
